Wood splitting tongs – Woodcracker L540 Ecoline

 Engineering and Design: Ground-Level Efficiency.
True to the “engineering for the woods” philosophy, the Woodcracker L540 stands out for its low-profile design, specifically developed to allow working extremely close to the ground. It is manufactured entirely from high-strength Hardox® steel and features premium pin bearings, ensuring an extended service life and exceptional resistance to mechanical wear. To withstand harsh environments, the entire structure undergoes a KTL (cathodic dip-priming) treatment and an anti-corrosive powder coating.

Performance: Compact Power.
The L540 Ecoline offers a 540 mm gripper opening, allowing it to engage logs with a splitting force of up to 14 tons. Its hydraulic system is optimized for low flow rates (25–60 l/min), facilitating seamless integration into a wide variety of base machines without compromising cycle speed. Thanks to its intelligent design, it requires very little force from the carrier machine to divide even the most resilient timber.

Biomass Quality and Versatility: The Multi-tasking Tool.
Pre-splitting with the L540 enables a natural wood seasoning process, significantly increasing biomass quality and its final energy yield. Beyond its primary function, its robustness allows it to be used as a conventional loading gripper, enabling the operator to split, organize, and feed chippers without the need to switch attachments.

Fleet Compatibility

• Base machines: Mini excavators, forestry trailers, timber cranes, and farm loaders. Mounting versatility: Available for excavator mounting or installations on trailers and cranes. Hydraulic Requirements:
• Recommended pump flow: 25 – 60 l/min.
• Recommended operating pressure: 180 – 240 bar.

Do you need a specific configuration? Contact us for a custom consultation to optimize your production.
————————————————-
Frequently Asked Questions (FAQ)

1. What warranty does the manufacturer offer? The Woodcracker L540 Ecoline comes with a manufacturer’s warranty of 1,500 hours or 1 year on parts (whichever comes first), securing your investment in the field.

2. Does it include technical documentation? Yes, the unit is delivered with the CE Certificate, a comprehensive user manual, and a spare parts book with all technical references to facilitate maintenance.

3. Can I use it to load logs in addition to splitting them? Absolutely. Thanks to its design, it functions perfectly as a loading gripper, allowing you to split and load timber in a single operation without changing tools.

4. How does using this splitter improve biomass? Pre-splitting exposes the interior of the log to the air, facilitating a much faster natural seasoning process. This reduces moisture content, prevents degradation, and significantly raises the energy value of the resulting wood chips.

5. Is it difficult to install on my mini excavator? Not at all. The design is “Plug-and-play,” allowing for a quick and easy hydraulic and mechanical connection so you can start working immediately.
