Excavator Mulcher Head – FAE PML/EX 125

Engineering and Design: Compactness and Low Maintenance.
The PML/EX is engineered to provide maximum durability with minimal operational effort. Its structure features an “anti-dust” internal body and an integrated Direct Drive motor, which not only reduces the head’s overall dimensions but also minimizes routine maintenance by eliminating complex transmission components. Additionally, it includes interchangeable Hardox wear skids, ensuring superior resistance against ground abrasion.

Performance and Power: Plug & Play Technology.
This head stands out for its ease of installation. The hydraulic motor is compatible with excavators that do not have a dedicated case drain line, allowing for a quick and direct connection. Equipped with a Flow Control valve featuring integrated safety and anti-cavitation systems, the PML/EX manages flow rates between 25 and 90 L/min, optimizing torque for smooth, consistent clearing without overloading the carrier’s hydraulic system.

Operational Quality: Cutting Versatility.
The PML/EX rotor offers exceptional flexibility to adapt to different types of vegetation. It can be equipped with 20 PML swinging hammers (standard) for light forestry mulching or with optional Y-blades for grass and bramble clearing. Its adjustable rear roller allows the operator to control the working height and ensures perfect ground following, leaving a clean and professional finish.

Fleet Compatibility:

• Recommended Excavators: 5 to 7.5-ton machines.
• Hydraulic Requirements: Flow rate of 25–90 L/min and pressure of 180–250 bar.
• Installation: Case-drain-free motor, facilitating easy swapping between different machines in the fleet.

Custom Configuration: Do you need a specific setup or bracket? Contact us for personalized technical advice.
——————————-
Frequented Asked Questions

1. What type of vegetation can the PML/EX 125 process? It is designed for light vegetation, shrubs, and branches up to 5 cm (2 inches) in diameter, making it ideal for plot clearing and roadside maintenance.

2. Is it compatible with my excavator if it doesn’t have a case drain line? Yes, it is a Plug & Play unit. The hydraulic motor is specifically designed to operate perfectly without the need for an external drain line.

3. What is the difference between using hammers or blades? PML hammers are better suited for wood and brush, while Y-blades are ideal for rapid clearing of grass and light weeds.

4. What maintenance does the Direct Drive system require? Maintenance is minimal compared to belt-driven systems, as the motor is coupled directly to the rotor, reducing wear points and complexity.

5. What warranty and support are included? We offer a warranty of 1,500 hours or one year for parts and labor. Additionally, 1 to 2 days of technical training and on-site commissioning are included with the delivery of the equipment.
