Saw Grapple – VOSCH 1510-7T

Name: Saw Grapple - VOSCH 1510-7T - FOREST PIONEER
Brand: VOSCH

High-performance saw head designed to optimize felling and handling for 9 to 12-ton excavators. With an optimized weight of 711 kg and a massive 44 kN clamping force, this equipment combines exceptional agility with the ruggedness required for the most demanding forestry tasks. It is the ultimate tool for professionals seeking total versatility in biomass management and selective felling.

Large description

Engineering and Design:

Professional-grade durability. The Vosch 1510 – 7t VC represents “forestry engineering at its best.” Built to withstand the harshest conditions, its design protects all critical hydraulic components, minimizing downtime. Its structure is optimized to offer excellent visibility of the cutting area, allowing the operator to work with surgical precision even in dense pine or eucalyptus stands.

Rotation and Performance:

Limitless agility. Equipped with two powerful rotation motors and a 220-bar main safety valve, this head offers smooth and controlled 360° movement. The hydraulic system is designed to operate at pressures up to 350 bar on the arms, ensuring every cutting and loading cycle is as efficient as possible. The combination of its two double-acting lines ensures immediate response and constant force throughout the workday.

Felling and Handling:

Precision in every move. With a maximum opening of 1560 mm, the Vosch 1510 can easily grasp and process large-volume stems. Its VC (Variable Cut) saw system ensures a controlled tree fall, increasing operator safety and protecting forest regeneration. It is not just a felling head; it is a heavy-duty loading grapple capable of handling logs and branches with superior automatic centering precision.

Fleet compatibility

Base machine type – Tracked or wheeled excavators
Recommended weight range – 9 – 12 tons
Required hydraulic flow – 40 l/min (grapples) / 25 l/min (rotation)
Working pressure – 350 bar (arms) / 180 bar (rotation)

Custom Adaptation: Do you need a specific configuration? Contact us for personalized advice.
—————————————

Frequently Asked Questions (FAQ)

1. What type of work is the Vosch 1510 ideal for?
It is perfect for land clearing, biomass management, thinning, and handling stacked timber. Its design is ideal for challenging forest stands, such as pine and eucalyptus plantations.

2. Is it difficult to adapt this head to my current excavator?
Not at all. It requires a double-acting circuit with two lines. Our technical service team handles the pressure and flow configuration so that the equipment performs at 100% from day one.

3. What maintenance does the saw unit require?
Maintenance is minimal thanks to its protected design. It only requires periodic checks of the chain sharpness and greasing of the pivot points, all clearly detailed in the included user manual.

4. What is included in the delivery package?
You will receive the felling head with a CE certificate, user manual, full parts book, and the manufacturer’s official warranty.

5. How does the warranty work?
We offer a full parts warranty for a period of one year or 1,500 working hours (whichever comes first), backed by our specialized technical support.

Additional information

Brand	VOSCH
Type	Bar saw head
Weight	711 kg
Opening	1,560 mm
Closing Force	44 kN
Flow Rate	40 l/min (Grapple) / 25 l/min (Rotation)
Operating Pressure	350 bar (Arms) / 180 bar (Rotation)
