Engineering and Design
Exclusive Forestry Design. Built for peak performance and engineered to last, the TR 130 SR is not a mere conversion but a pure-bred forestry machine. Its structure is ROPS/FOPS certified and incorporates OPS-certified polycarbonate glazing as standard to ensure maximum operator safety. The protection package is comprehensive: HD (Heavy Duty) engine hood reinforcements, hose protection on the boom and stick, HD belly plating for the slew ring, and full-length forestry track guards. Furthermore, its Short Radius design allows for maneuvering in dense thinnings without the risk of rear-swing collisions with standing trees.
Power and Hydraulic Performance
The heart of the machine is a 130 HP Cummins B4.5 engine, providing class-leading power. To guarantee productivity, it features a high-flow hydraulic system (315 l/min) with dedicated flow for the attachment, allowing multiple work functions to operate simultaneously without speed loss. Thermal management is handled by a reversible hydraulic fan with variable speed control, ensuring continuous operation without overheating in any season or climate.
Versatility and Ergonomics
Designed for comfort and efficiency, the cabin is equipped with 360° LED lighting, a front emergency exit, and an easily accessible toolbox. As a “connected” machine, it offers data analytics and alerts for proactive maintenance. The undercarriage is highly configurable, with track shoe (pad) options ranging from 500 mm to 800 mm, maintaining ground pressure between 0.34 and 0.54 kg/cm²—ideal for minimizing the environmental footprint on sensitive forest soils.
Fleet Compatibility: Thanks to its high-flow circuit, the FPM TR 130 SR is the ideal base machine for a wide range of professional attachments.
Available Hydraulic Configurations:
- High Flow Line: 250 l/min at 350 bar.
- Low Flow Line: 40 l/min at 180 bar.
- Optional: Dedicated circuit for rotating attachments (includes drain and electrical lines).
Factory Recommended Attachments:
- Processor Heads: AFM 45 and AFM 55.
- Disc Feller Heads: TRIM 380.
- Forestry Mulchers: FAE BL2/S – UML/EX.
- Other: Westtech shears, Vosch saw grapples.
Custom Adaptation: Do you need a specific configuration? Contact us for personalized technical advice.
—————
Preguntas frecuentes (FAQ)
1. What does “SR” stand for? SR stands for Short Radius. This means the machine’s counterweight remains within (or very close to) the track width during rotation, making it perfect for working in thinnings or narrow trails without the risk of hitting trees behind the machine.
2. Is the flow sufficient for a forestry mulcher? Yes, the TR 130 SR delivers up to 315 l/min at 350 bar. We specifically recommend models like the FAE BL2/S or UML/EX for this machine to ensure fluid and efficient operation.
3. Does it come protected for forestry work or does it require adaptation? The TR 130 SR is a native forestry machine (Exclusive Forestry Design) that meets all current ROPS/FOPS/OPS standards. It includes factory-installed belly guards, hose protection, polycarbonate windows, hood guards, and anti-derailment track guides. No additional external adaptation is required.
4. What engine does it use and what is its actual power? True to its nomenclature, it features a powerful Cummins B4.5 engine developing 130 HP. This gives it a power-to-weight ratio far superior to other machines in its size class.
5. How is the machine transported? It is extremely compact for its power. It has a transport length of 6,965 mm and a height of 3,120 mm. With standard track shoes, the width remains at 2,490 mm, facilitating transport on conventional lowboys without the need for over-width permits.
